Flameproof Switchgear
Exclusive range of FLP switchgear from start - stop stations, switch socket, junction box, emergency station, hooter with various current and voltage options. ILS switchgear are made of die-casted enclosure and heat-sink for best performance and reliability to offer maintenance free operation for years. Suitable for Chemical Industry, Paint Industry, Fertilizer Industry, Oil & Gas Industry, LPG Bottling Industry, Pharma Industry, Steel Industry, Cement Industry, Mines, Refineries & Petrochemicals,.
CIMFR, PESO and BIS certified for IIA, IIB, IIC Zone 1 & 2
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Plastic |
| Shape | Rounded |
| Color | Grey |
| Max. Voltage | 240V |
| Surface Finishing | Coated |
| Specialities | Rust Proof |
| Power | 1NO + 1NC, 10A, 24/240/415V AC/DC |
| Model | IFJ10 |
Features:
- Fire & Ignition proof.
- AL die-cast LM-6 housing.
- Two earthing for better safety-internal & external.
- Neoprene gasket for trouble free long life.
- External hardware made of SS.
- High rating contacts 10A, 24/240/415 V AC/DC
- Highly reliable professional design.
Applications:
- Chemical, paint, fertilizer industries,
- Oil & gas, refinery, petrochemicals,
- LPG bottling, pharmaceutical
- Steel, Cement industries, Mines
Standards Compliance
IS/IEC 60079-1:2014
Options
- Canopy — Light Grey 631 epoxy paint ( GI/MS/FPR)
- Cable Gland — M20 or 5" NPT (Brass/AL/SS304/SS316)
- Stopper plug — M20 or 1/2' NPT (Brass/AUSS304/SS316)
- Start Push Button — KEY operated
- Hood Cable Gland — PVC, Black Color
- Feed terminal — DIN rail — Screw Type 2.4/4/6 sq mm
- Packing — Wooden
Applicable Use
- Zone 1 & Zone 2
- Gas group IIA, IIB, IIC, IIIC, Temperature class T6
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Plastic |
| Color | Grey |
| Max. Voltage | 240V |
| Surface Finishing | Coated |
| Specialities | Rust Proof |
| Model | IFJ12 |
| Power | ON/OFF, 32A, 24/240/415V AC/DC |
Features:
- Fire & Ignition proof.
- AL die-cast LM-6 housing.
- Two earthing for better safety-internal & external.
- Neoprene gasket for trouble free long life.
- External hardware made of SS.
- High rating contacts 10A, 24/240/415 V AC/DC
- Highly reliable professional design.
Applications:
- Chemical, paint, fertilizer industries,
- Oil & gas, refinery, petrochemicals,
- LPG bottling, pharmaceutical
- Steel, Cement industries, Mines
Standards Compliance
IS/IEC 60079-1:2014
Options
- Canopy — Light Grey 631 epoxy paint ( GI/MS/FPR)
- Cable Gland — M20 or 5" NPT (Brass/AL/SS304/SS316)
- Stopper plug — M20 or 1/2' NPT (Brass/AUSS304/SS316)
- Start Push Button — KEY operated
- Hood Cable Gland — PVC, Black Color
- Feed terminal — DIN rail — Screw Type 2.4/4/6 sq mm
- Packing — Wooden
Applicable Use
- Zone 1 & Zone 2
- Gas group IIA, IIB, IIC, IIIC, Temperature class T6
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Plastic |
| Color | Grey |
| Voltage | 240V |
| Power | 16A/25A/32A |
| Surface Finishing | Power Coated |
| Specialities | Good Quality, Easy To Use |
| Model | IFJ13 |
Features:
- Fire & Ignition proof.
- AL die-cast LM-6 housing.
- Two earthing for better safety-internal & external.
- Neoprene gasket for trouble free long life.
- External hardware made of SS.
- High rating contacts 10A, 24/240/415 V AC/DC
- Highly reliable professional design.
Applications:
- Chemical, paint, fertilizer industries,
- Oil & gas, refinery, petrochemicals,
- LPG bottling, pharmaceutical
- Steel, Cement industries, Mines
Standards Compliance
IS/IEC 60079-1:2014
Options
Canopy — Light Grey 631 epoxy paint ( GI/MS/FPR)
- Cable Gland — M20 or 5" NPT (Brass/AL/SS304/SS316)
- Stopper plug — M20 or 1/2' NPT (Brass/AUSS304/SS316)
- Start Push Button — KEY operated
- Hood Cable Gland — PVC, Black Color
- Feed terminal — DIN rail — Screw Type 2.4/4/6 sq mm
- Packing — Wooden
Applicable Use
- Zone 1 & Zone 2
- Gas group IIA, IIB, IIC, IIIC, Temperature class T6
| Business Type | Manufacturer, Exporter, Supplier |
| Packaging Type | Box |
| Specialities | High Quality |
| Material | Aluminium |
| Shape | Rounded |
| Color | Grey |
| Max. Voltage | 240V |
| Mechanical Life | 2 Year |
| Surface Finishing | Coated |
| Country of Origin | India |
| Current Rating | 6A |
| No Of Switch | 2 Switch |
| Switch Operation | ON/OFF |
| Degree of Protection | IP66 |
| Model | IFJ11 |
| Power | 1NO + 1 NC, 32A, 24/240/415V AC/DC |
| Product Code | IFJ20-XXXXXXXXXX |
| Payment Terms | T/T |
| Delivery Time | 21 Days |
| Packaging Details | 5 Ply Corrugated Box |
Features:
- Fire & Ignition proof.
- AL die-cast LM-6 housing.
- Two earthing for better safety-internal & external.
- Neoprene gasket for trouble free long life.
- External hardware made of SS.
- High rating contacts 10A, 24/240/415 V AC/DC
- Highly reliable professional design.
Applications:
- Chemical, paint, fertilizer industries,
- Oil & gas, refinery, petrochemicals,
- LPG bottling, pharmaceutical
- Steel, Cement industries, Mines
Standards Compliance
IS/IEC 60079-1:2014
Options
- Canopy — Light Grey 631 epoxy paint ( GI/MS/FPR)
- Cable Gland — M20 or 5" NPT (Brass/AL/SS304/SS316)
- Stopper plug — M20 or 1/2' NPT (Brass/AUSS304/SS316)
- Start Push Button — KEY operated
- Hood Cable Gland — PVC, Black Color
- Feed terminal — DIN rail — Screw Type 2.4/4/6 sq mm
- Packing — Wooden
Applicable Use
- Zone 1 & Zone 2
- Gas group IIA, IIB, IIC, IIIC, Temperature class T6
